Shop Pumps & Filters
JP 5-48 PM1
$1,360.45 (Incl GST)
incl GST
Suitable for
- Domestic ground water intake
- Domestic water pressure boosting
- Domestic rainwater harvesting
JP PM are boosters that consist of a pressure manager and a self-priming, single-stage centrifugal pump. Designed for a wide range of garden and domestic applications, including water supply and transfer duties in the home.
Product number 99463901
Description
Specifications
| Product name | JP 5-48 PM1 A-A-BBVP |
| Product No | 99463901 |
| EAN number | 5713829542716 |
Technical
| Rated flow | 5 m³/h |
| Rated head | 45.6 m |
| Primary shaft seal | BBVP |
| Approvals | CE,WM,C-TICK |
| Curve tolerance | ISO9906:2012 3B |
| Pump version | A |
| Adjustable start pressure | N |
| Start pressure | 1.5 bar |
| Rated driver speed | 2800 rpm |
Materials
| Pump housing | Stainless steel |
| EN 1.4301 | |
| AISI 304 | |
| Impeller | Composite |
| Material code | A |
Installation
| Minimum ambient temperature | 0 °C |
| Maximum ambient temperature | 40 °C |
| Maximum operating pressure | PN 6 bar |
| Pump inlet | G 1 |
| Pump outlet | G 1 |
Liquid
| Pumped liquid | Water |
| Liquid temperature range | 0 .. 40 °C |
| Selected liquid temperature | 20 °C |
| Density | 998.2 kg/m³ |
Electrical data
| Power input – P1 | 1490 W |
| Mains frequency | 50 Hz |
| Rated voltage | 1 x 230 V |
| Rated current | 6.6 A |
| Starting current | 27.9 A |
| Capacitor size – run | 25 µF/450 V |
| Enclosure class (IEC 34-5) | IP44 |
| Insulation class (IEC 85) | F |
| Length of cable | 1.5 m |
| Type of cable plug | AUS |
Others
| Net weight | 14 kg |
| Gross weight | 15 kg |
Additional information
| Weight | 14 kg |
|---|
