Puretec Maxi Plus Filter Housing Kit, 10 inch, Grey, 1 ½" (40mm) connections

$270.68 (Incl GST)

The Puretec MP200B filter housings offer the versatility to meet all of your large-capacity filtration needs, including high-flow and heavy sediment applications. The extra-large housings allow for greater cartridge capacity, reducing the number of vessels required for high flow-rate applications. Sumps are constructed of durable reinforced polypropylene. Includes spanner & stainless steel mounting bracket.

Description

FEATURES & BENEFITS

• High capacity filter housings.
• Features double O-ring seals for maximum durability. • Ribbed design provides a robust housing for years of trouble-free service.
• Compact and economical, ideal for duplex systems.
• Wide variety of cartridge replacement available.
• Internal and external use to suit different applications.

SPECIFICATIONS

Ordering Code: MP200B
Size: 10″
Min/Max Ambient Temperature: 0 – 52°C
Min/Max Pressure: 0 – 520 kPa
Min/Max Flow Rate: 85 Lpm
Connection: 1½” (40 mm)
Warranty: 10 years^
^10 year warranty is 1 year parts and labour, plus 9 years parts only. Pressure + Temperature ratings mean housings must be protected from extremes above and below. This includes freezing, vacuum, overnight pressure creep + water hammer.

Additional information

Weight 1 kg
